Magnetek IMPULSE G+ Series 4 Drives
Typical Lead Time: 5 - 80 Working Days (Drop Shipped Item)
Shipping: Freight
Lead times may vary and is determined by a variety of factors. Contact Bohl Crane, Inc. for precise lead times and product availability.
Overview:
The Magnetek IMPULSE® G+ Series 4 drives are designed especially for material handling applications, providing a complete package of crane-specific capabilities far beyond a general purpose drive's functionality. IMPULSE G+ Series 4 can be used as an open-loop vector or V/F crane control for traverse motions or mechanical load brake hoists.
Features:
- Magnetek drives are designed with reliability and economy in mind
- Load Check II™ continuously detects hoist overload conditions, halting upward motion and only allowing the load to be lowered
- Safe Torque Off provides a redundant hardware safety circuit that guarantees motor and brake power are removed when an E-Stop switch or safety controller opens the drive input, eliminating the need for external disconnects
- Quick-Set™ is provided by the easy-to-use keypad and X-Press Programming™ so you get up and running right away
- Option cards provide the drive flexibility needed with expandable AC digital input and output, DC digital and analog input and output option cards
- Compatible with 50HZ voltage making them available for use in all European countries
- Adaptive Ultra-Lift™ allows for hoist operation above base speed with a light load or empty hook
- Safe lifting features are built right in, including Torque Proving, which confirms the motor is providing enough torque to safely lift a load prior to releasing the brake
- IMPULSE Link Diagnostic System maximizes the efficiency of your drive by providing easy parameter management right on your PC
- User-friendly keypad gives you 5 lines of 16 characters each and includes soft keys and upgraded parameter selection. The display makes navigation and reading diagnostics even easier.
- Rated input power supply volts & frequency: 3-phase 200-240 VAC, 380-480 VAC, or 500-600 VAC; 50 or 60Hz
Note: Horsepowers are provided for reference only and should not be used for sizing drives. Drives should be sized according to actual motor Full Load Amps (FLA). Prices and data subject to change without notice.
- Allowable input frequency fluctuation: ±5% of nominal
- Circuit protection: ground fault and blown-fuse protection
- Up to 17 distinct speeds (stepped), 2-step infinitely variable, 3-step infinitely variable
- Analog Signal (0-10 VDC, 4-20mA, ±10 VDC)
- Digital Pulse Train Input (32kHz max)
- Radio Drive Serial Interface (RDSI)
- Certification: UL, cUL, CSA, RoHS (CE available with filters)
- CMAA Class A-F Service
- AISE TR6 Class 1 to 4
- ASME HST-4M H1 to H5
- Speed Range - 40:1 in V/F Mode (15 present V/F Patterns, 1 Adjustable), 200:1 in Open Loop Vector Mode
- 3 year warranty
PRODUCT NUMBER | MAX. MOTOR FLA | MOTOR HP |
460 Volts | ||
4001-G+S4-120-0-0-0-OPEN-STD | 1.8 | 0.75 |
4003-G+S4-120-0-0-0-OPEN-STD | 3.4 | 1 |
4004-G+S4-120-0-0-0-OPEN-STD | 4.8 | 2 |
4005-G+S4-120-0-0-0-OPEN-STD | 5.5 | 3 |
4007-G+S4-120-0-0-0-OPEN-STD | 7.2 | 5 |
4009-G+S4-120-0-0-0-OPEN-STD | 9.2 | 5 |
4014-G+S4-120-0-0-0-OPEN-STD | 14.8 | 7.5 |
4018-G+S4-120-0-0-0-OPEN-STD | 18 | 10 |
4024-G+S4-120-0-0-0-OPEN-STD | 24 | 15 |
4031-G+S4-120-0-0-0-OPEN-STD | 31 | 20 |
4039-G+S4-120-0-0-0-OPEN-STD | 39 | 25 |
4045-G+S4-120-0-0-0-OPEN-STD | 45 | 30 |
4060-G+S4-120-0-0-0-OPEN-STD | 60 | 40 |
4075-G+S4-120-0-0-0-OPEN-STD | 75 | 50 |
4091-G+S4-120-0-0-0-OPEN-STD | 91 | 60 |
4112-G+S4-120-0-0-0-OPEN-STD | 112 | 75 |
4150-G+S4-120-0-0-0-OPEN-STD | 150 | 100 |
4180-G+S4-120-0-0-0-OPEN-STD | 180 | 125 |
4216-G+S4-120-0-0-0-OPEN-STD | 216 | 150 |
4260-G+S4-120-0-0-0-OPEN-STD | 260 | 200 |
4304-G+S4-120-0-0-0-OPEN-STD | 304 | 250 |
4370-G+S4-120-0-0-0-OPEN-STD | 370 | 300 |
4450-G+S4-120-0-0-0-OPEN-STD | 450 | 350 |
4605-G+S4-120-0-0-0-OPEN-STD | 605 | 500 |
4810-G+S4-120-0-0-0-OPEN-STD | 810 | 650 |
41090-G+S4-120-0-0-0-OPEN-STD | 1090 | 900 |
230 Volts | ||
2003-G+S4-120-0-0-0-OPEN-STD | 3.2 | 0.75 |
2005-G+S4-120-0-0-0-OPEN-STD | 5 | 1 |
2007-G+S4-120-0-0-0-OPEN-STD | 6.9 | 2 |
2008-G+S4-120-0-0-0-OPEN-STD | 8 | 2 |
2011-G+S4-120-0-0-0-OPEN-STD | 11 | 3 |
2014-G+S4-120-0-0-0-OPEN-STD | 14 | 3 |
2017-G+S4-120-0-0-0-OPEN-STD | 17.5 | 5 |
2025-G+S4-120-0-0-0-OPEN-STD | 25 | 7.5 |
2033-G+S4-120-0-0-0-OPEN-STD | 33 | 10 |
2047-G+S4-120-0-0-0-OPEN-STD | 47 | 15 |
2060-G+S4-120-0-0-0-OPEN-STD | 60 | 20 |
2075-G+S4-120-0-0-0-OPEN-STD | 75 | 25 |
2085-G+S4-120-0-0-0-OPEN-STD | 85 | 30 |
2115-G+S4-120-0-0-0-OPEN-STD | 115 | 40 |
2145-G+S4-120-0-0-0-OPEN-STD | 145 | 50 |
2180-G+S4-120-0-0-0-OPEN-STD | 180 | 60 |
2215-G+S4-120-0-0-0-OPEN-STD | 215 | 75 |
2283-G+S4-120-0-0-0-OPEN-STD | 283 | 100 |
2346-G+S4-120-0-0-0-OPEN-STD | 346 | 125 |
2415-G+S4-120-0-0-0-OPEN-STD | 415 | 150 |
575 Volts | ||
5001-G+S4-120-0-0-0-OPEN-STD | 1.7 | 1 |
5003-G+S4-120-0-0-0-OPEN-STD | 3.5 | 2 |
5004-G+S4-120-0-0-0-OPEN-STD | 4.1 | 3 |
5006-G+S4-120-0-0-0-OPEN-STD | 6.3 | 5 |
5009-G+S4-120-0-0-0-OPEN-STD | 9.8 | 7.5 |
5012-G+S4-120-0-0-0-OPEN-STD | 12.5 | 10 |
5017-G+S4-120-0-0-0-OPEN-STD | 17 | 15 |
5022-G+S4-120-0-0-0-OPEN-STD | 22 | 20 |
5027-G+S4-120-0-0-0-OPEN-STD | 27 | 25 |
5032-G+S4-120-0-0-0-OPEN-STD | 32 | 30 |
5041-G+S4-120-0-0-0-OPEN-STD | 41 | 40 |
5052-G+S4-120-0-0-0-OPEN-STD | 52 | 50 |
5062-G+S4-120-0-0-0-OPEN-STD | 62 | 60 |
5077-G+S4-120-0-0-0-OPEN-STD | 77 | 75 |
5099-G+S4-120-0-0-0-OPEN-STD | 99 | 100 |
5130-G+S4-120-0-0-0-OPEN-STD | 130 | 125 |
5172-G+S4-120-0-0-0-OPEN-STD | 172 | 150 |
5200-G+S4-120-0-0-0-OPEN-STD | 200 | 200 |
