Expansion Sections | Magnetek Electrobar 8-Bar Conductor Bar Components | 8-90E & 8-90E-G
Typical Lead Time: 5 - 7 Working Days (Drop Shipped Item)
Shipping: Freight (Please contact Bohl Crane)
Overview:
These expansion sections are complete 10 ft. assemblies, shipped with power feed and two anchor hangers. Expansions should be used at all building expansion joints, and compensate for ambient and environmental temperature variations.
Magnetek's Electrobar 8-Bar Enclosed Conductor Bar Systems are the practical, proven and economical way to deliver electricity to overhead cranes, hoists, monorails, and other types of moving equipment.
Please contact Bohl Crane, Inc. if a different component is needed for your system.
- Expansion Considerations/Anchor Locations for 90 Amp Steel Conductor Bar Systems:
- Mid-Span for straight systems 300 feet long
- Every 150 feet for straight systems over 300 feet long
- All Systems:
- At all building expansion joints
| Product Number | Description | Weight |
| 8-90E |
90 Amp Rolled Galvanized Steel Expansion - Orange Cover |
6.80 lbs. |
| 8-90E-G | 90 Amp Rolled Galvanized Steel Expansion - Green Cover (Ground) | 6.80 lbs. |
Not quite what you're looking for? Please contact Bohl Crane, Inc. for more information.
